NORMACONNECT® FGR PLAST GRIP E | NBR | W5
Brand:
NORMA
| Article number: | NOR-5818660040 |
| EAN: | 4043171606394 |
| SKU: | 5818660040 |
- 2 year warranty
- Delivery time: on request
- Customer service 09:00 - 17:00
Information
NORMACONNECT® FGR PLAST GRIP E | NBR | W5
The pipe coupling for Plastic pipes.
FGR Plast Grip E are axially tensile pipe couplings for connecting plastic pipes. The specially developed anchor ring with flat rows of teeth grips the pipe surface without damaging it. The applied force is evenly distributed over the pipe surface.
FGR PLAST GRIP E are axially tensile pipe couplings for connecting plastic pipes. A support ring must be used for pipes made of soft thermoplastics (PE, HDPE, PB).
Characteristics:
- Sizes: 40,0 mm – 160,0 mm
- Working pressure: 16.0 – 6.0 bar
- Material: W5 (AISI 316, 1.4571/1.4401)
Temperature:
- EPDM: 26.9 – 168.3mm: -30ºC to +125ºC; > 180.0 mm: -20ºC to +80ºC (Click here for the EPDM version)
- NBR: -20ºC to +80ºC
Advantages:
- Time-saving installation: no welding, pre-alignment or pipe end treatment required
- Space-saving: can be installed in hard-to-reach places
- Pipe tolerance compensation and angular distortion compensation
Applications:
- shipbuilding
- offshore
- machine building
- (petro-)chemical industry
- sewerage works
The NORMACONNECT ® PLAST GRIP E is almost identical to the NORMACONNECT ® PLAST GRIP. The PLAST GRIP E has hollow trunnions containing the bolts, the PLAST GRIP has solid trunnions and are mounted on the couplings > 160.0 mm.
New datasheet:
Old datasheet:
Productcode:
05818660040 – 05818660050 – 05818660063 – 05818660075 – 05818660090 – 05818660110 – 05818660125 – 05818660140 – 05818660154 – 05818660160
0581 8660 040 – 0581 8660 050 – 0581 8660 063 – 0581 8660 075 – 0581 8660 090 – 0581 8660 110 – 0581 8660 125 – 0581 8660 140 – 0581 8660 154 – 0581 8660 160
EAN:
4043171606394 – 4043171606431 – 4043171616355 – 4043171497992 – 4043171616386 – 4043171326063 – 4043171617215 – 4043171617215 – 4043171616430 - 4043171617215
Specifications
| Bolt: | M8 SW6 - M10 SW8 - M12 SW10 |
| Bandwidth: | See PDF |
| Tightening torque (Maximum): | See PDF |
