IQ-Parts GBS Hose Clamp tailor made | W2 (AISI 430) | double bolts | 20 - 25 - 30 mm width
Brand:
IQ-Parts
| Article number: | IQP-GBS-W2-2B-20-0150-0400 |
| SKU: | IQP-GBS-W2-2B-20-0150-0400 |
- 2 year warranty
- Delivery time: 1 week after order date
- Customer service 09:00 - 17:00
Information
IQ-Parts GBS Hose Clamp tailor made | W2 (AISI 430) | double bolts | 20 - 25 - 30 mm width
This heavy duty hose clamp with bridge section is used in applications where the hose clamp must meet strict requirements. The clamp is very suitable for applications with suction and discharge hoses with a high hardness and hoses with plastic or steel inserts. The GBS clamps can withstand high belt tension forces.
Quality:
- Band and bridge = W2 (AISI 430, 1.4016)
- Bolts and nuts = galvanized steel.
This clamp is available in 3 different band widths:
- 20 mm width
- 25 mm width
- 30 mm width
In the drop-down menu, choose the bandwidth and enter the desired diameter (At least 150 mm). If you need a diameter greater than 400 mm or if you want more than 2 bolts, please contact our sales department.
The diameter can be changed by adjusting the bolt:
- 20 mm wide: +/- 5.0 mm, bolt is M6
- 25 mm wide: +/- 8.0 mm, bolt is M8
- 30 mm wide: +/- 10.0 mm, bolt is M10
Look at RELATED PRODUCTS for the following variants:
- W2 quality and 1 bolt
- W4 quality (AISI 304, 1.4301) and 1 bolt
- W4 quality (stainless steel 304, 1.4301) and 2 bolts
- Rubber C-profile
Applications
-
Engineering
-
Chemischel industry
-
Food industry
-
Railways
-
Construction machinery
-
Pump and filter systems
This is a product that is tailor-made for you. Exchange is therefore not possible!
Specifications
| Bolt: | M6 / M8 / M10 |
| Bandwidth: | 20/25/30 mm |
| Tightening torque (Maximum): | 30 - 50 Nm (Max.) |
