IQ-Parts Power-Clamp W1 | double bolt | 20/25 mm
Brand:
IQ-Parts
Article number: | IQP-W1-2D-20-055-065 |
- 2 year warranty
- Delivery time: 1 week
Information
IQ-Parts Power-Clamp W1 | double bolt | 20/25 mm
Power-Clamps are designed for heavy-duty industrial hose connections. The W1 double bolt Power-Clamp is configured with one bolt and is fitted with a bridge with raised edges, which prevent shearing of the hose material.
The Power-Clamp W1 | double bolt | 20/25 mm is suitable for many applications.
Material:
- Screw: M6 x 45, DIN 912, W1 (8.8)
- Band:
- ø 55 - 90 mm = 20 mm width,
- ø 105 - 170 mm = 25 mm width
- 1mm thick, DIN 1623 W1 (St.12.03) White gegalvanized (Cr3)
Typical applications can be found in the following areas:
- Agricultural
- Drainage systems
- Irrigation systems
- Cooling systems
- Sludge suction systems
Specifications
Bolt: | M6 x 45 |
Bandwidth: | 20 mm / 25 mm |
Tightening torque (Maximum): | 10 Nm (Maximum) |
