Mikalor P-Clip 25 mm W1 DIN 3016
Brand:
Mikalor
- Buy 100 for €1,30 each and save 10%
- Buy 250 for €1,15 each and save 20%
- Buy 500 for €1,01 each and save 30%
| Article number: | MKL-LK-25-W1-15 |
| SKU: | 03006344 |
- 2 year warranty
- Delivery time: Delivery in 1 to 2 days
- Customer service 09:00 - 17:00
Information
Mikalor P-Clips 25 mm W1 DIN 3016
DIN 3016 Rubber-lined P-Clip (Form D) These rubber-lined connecting clamps, also known as “P-Clips” are composed of a zinc-plated mild steel band lined with EPDM rubber. This rubber lining allows for firm and safe clamping in the application zone and prevents potential damage due to vibration. The screw holes at either end of the band are reinforced with steel plates to ensure they clamp down firmly. P-Clips are particularly recommended for mounting pipes, electric cable ducting and hoses in a multitude of different applications.
The scope of delivery does not include bolts or nuts.
We recommend:
For NORMAFIX® RS/RSGU with 12mm band width: M5 bolt
For NORMAFIX® RS/RSGU with 15mm band width: M6 bolt
For NORMAFIX® RS/RSGU with 20mm band width: M8 bolt
* P-Clips can be supplied in bandwidths of up to 25mm and in diameters up to 100 mm.
* Other models of DIN 3016 P-Clips are also available on request: Forms A,B,C,E and F and also without
rubber.
* Other types of rubber lining are also available.
* Other models of DIN 3016 P-Clips are also available on request: Forms A,B,C,E and F and also without
rubber.
* Other types of rubber lining are also available.
This P-Clip can only be ordered per full package*:
- Ø 15 mm to ø 22 mm & ø 54 mm VPE is 100 pieces
- Ø 24 mm to ø 68 mm VPE is 50 pieces
*If you want to order less than the VPE, please contact our sales department to find out what the possibilities are.
Product code:
03006344 - 03006352 - 03006360 - 03006379 - 03006387 - 03006395 - 03006416 - 03006432 - 03006459 - 03006475 - 03006491 - 03006512 - 03006539 - 03006555 - 03006571 - 03006598 - 03006619 - 03006635 - 03006651 - 03006678 - 03006694 - 03006715 - 03006731 - 03006758 - 03006774 - 03006790 - 03006811 - 03006838 - 03006854 - 03006870
Specifications
| Bandwidth: | 25 mm |
| Rubber: | EPDM |
