NORMAQUICK® V2 straight Quick Connector 0° NW27 - 29 mm - NBR

€11,45 Incl. tax
€9,46 Excl. tax
* Excl. tax | Excl. Shipping costs
Now 67 in stock
Delivery time: Delivery in 1 to 2 days
  • Buy 10 for €8,51 each and save 10%
  • Buy 25 for €7,57 each and save 20%
  • Buy 50 for €6,62 each and save 30%
Article number: NOR-7138009027
EAN: 4043171344944
SKU: 7138009027
  • 2 year warranty
  • Delivery time: Delivery in 1 to 2 days
Information

Normaquick® V2 Straight Quick Connector 0º NW27 with 29 mm hose connection, with NBR sealing.

V2 plastic quick connectors are an ideal means to connect media carrying lines as well as ventilation and exhaust lines in automotive industry. The connectors can be used for both line-to-line and line-to-device connections. V2 can be applied on both plastic and metal spigots. NORMAQUICK® V2 plug connections are available as standard in the connection variants 0°, 45°, 50° and 90°.

"The NORMAQUICK V2 is only available with locking through the outer ring"

The advantages at a glance
  • Quick assembly time equaling cost reduction
  • Automated production, no human factor means less margin of error
  • No tools needed
  • Compact dimensions allowing ease of use in narrow spaces
  • An integrated seal provides optimal tightness
  • All seals can be visually checked, permitting safe assembly
  • Featuring extremely low permeation values


Technical Drawing:

EAN: 4043171344944

Product code:
07138009027 - 07137009027 - 07136009027 - 0713 8009 027 - 0713 7009 027 - 0713 6009 027
Specifications
Medium: Fuel tank ventilation, Ventilation and exhaust lines , Oil cooler lines, Vacuum brake line
Operating Pressure: Approx. 2,5 bar excess pressure
Temperature range: –40°C to +135°C, Short time up to +150°C (approx. 30 min.)
Material: Polyamide 6 with 30% glass fiber content or Polyamide 12 with 20% glass fiber
Size: NW27
Connection:
Seal: NBR
Hose connection: 29 mm Inner diameter
Weight:
NORMA NORMAQUICK® V2 straight Quick Connector 0° NW27 - 29 mm - NBR
