NORMAQUICK® V2 straight Quick Connector 90° NW27 - 29 mm - NBR

€11,45 Incl. tax
€9,46 Excl. tax
* Excl. tax | Excl. Shipping costs
Now 0 in stock
Delivery time: 2 - 3 weeks
  • Buy 10 for €8,51 each and save 10%
  • Buy 25 for €7,57 each and save 20%
  • Buy 50 for €6,62 each and save 30%
Article number: NOR-7138030027
SKU: 7138030027
  • 2 year warranty
  • Delivery time: 2 - 3 weeks
Information

Normaquick® V2 Straight Quick Connector 90º NW27 with 29 mm hose connection, with NBR sealing.

V2 plastic quick connectors are an ideal means to connect media carrying lines as well as ventilation and exhaust lines in automotive industry. The connectors can be used for both line-to-line and line-to-device connections. V2 can be applied on both plastic and metal spigots. NORMAQUICK® V2 plug connections are available as standard in the connection variants 0°, 45°, 50° and 90°.

"The NORMAQUICK V2 is only available with locking through the outer ring"

The advantages at a glance
  • Quick assembly time equaling cost reduction
  • Automated production, no human factor means less margin of error
  • No tools needed
  • Compact dimensions allowing ease of use in narrow spaces
  • An integrated seal provides optimal tightness
  • All seals can be visually checked, permitting safe assembly
  • Featuring extremely low permeation values

This concerns the version where the hose connection is 24 mm long.
We also sell the Normaquick V2 90º NW27 - 29 mm with a hose connection of 19.5 mm long (713 8010 027)


Technical Drawing:

Product code:
07138030027 - 07137030027 - 07136030027 - 0713 8030 027 - 0713 7030 027 - 0713 6030 027
Specifications
Medium: Fuel tank ventilation, Ventilation and exhaust lines , Oil cooler lines, Vacuum brake line
Operating Pressure: Approx. 2,5 bar excess pressure
Temperature range: –40°C to +135°C, Short time up to +150°C (approx. 30 min.)
Material: Polyamide 6 with 30% glass fiber content or Polyamide 12 with 20% glass fiber
Size: NW27
Connection: 90°
Seal: NBR
Hose connection: 29 mm Inner diameter | 24 mm long
Weight:
NORMA NORMAQUICK® V2 straight Quick Connector 90° NW27 - 29 mm - NBR
