CPC - PLCD10006V | Coupling body | Acetal | 3/8" NPT Pipe thread (BMW)
Brand:
CPC
| Article number: | CPC-PLCD10006V |
| SKU: | PLCD10006V |
- 2 year warranty
- Delivery time: 2 - 3 weeks
Information
CPC - PLCD10006V | Coupling body | Acetal | 3/8" NPT Pipe thread (BMW)
The PLCD10006V coupling, with shut-off valve and a 3/8" NPT thread (conical, self-sealing) from CPC, is the tank side coupling for screwing in. The integrated VITON seal (FKM) makes the PLCD10006V suitable for use in connection with fuel.
Installation recommendation for the CPC quick couplings:
- Lubricate the coupling threads with Loctite 243
- Screw the coupling into the threads of the tank plate by hand
- Tighten ½ to ¾ turn with a wrench
Keep in mind that:
After mounting, 2-3 turns of thread of the coupling are still visible above the tank plate, this is normal as the coupling has a conical thread and the thread in the tank plate is cylindrical.
Wait a day for the Loctite to set before filling the tank.
General information about the PLC series:
The 1/4" flow PLC Series is proven worldwide in thousands of applications and offers the widest selection of sizes and configurations. PLC couplings are injection molded from acetal thermoplastic and are resistant to most mild chemical solutions. One-hand connection/disconnection, plus integral terminations make the PLC Series the choice for ease of use and manufacture.
These couplings offer the flexibility of multiple configurations and terminations and mate with PLC-serie, LC-metal series and PLC12-serie polypropylene couplings. For more technical information, see the PDF.
- Material: Acetal, thumb latch is stainless steel
- Available in various sizes: from 1.6 mm to 6.4 mm ID, also at an angle of 90º
- Available with clamping ring coupling, hose tail or male or female thread
- With and without valve, Valve spring made of stainless steel 316 (W5)
- Available with panel mounting option
- O-rings: Viton (FKM)
- Vacuum up to 8.3 bar (120 PSI)
- Temperature range: -40ºC to 82ºC constant
Look at related products for the right choice for your application or contact our sales department: [email protected]
Specifications
| Medium: | Liquid / Air / Petrol |
| Operating Pressure: | 8,3 bar Vacuum |
| Temperature range: | –40° C tot +82° C |
| Material: | Acetal |
| Size: | 1/4" flow |
| Connection: | Quick coupling |
| Seal: | Viton (FKM) |
| Hose connection: | 3/8" NPT Pipe Thread |
| Weight: | -- |
