UNEXIS Safety hose clamps NS | Standard | Stainless Steel | Conductive
Brand:
UNEXIS
| Article number: | UNE-NS-STAND |
| SKU: | UNE-NS-STAND |
- 2 year warranty
- Delivery time: on request
- Customer service 09:00 - 17:00
Information
UNEXIS Safety hose clamps NS | Standard | Stainless Steel | Conductive
UNEXIS Safety hose clamps guarantee a high degree of sealing and are proven to be effective. The clamps are widely used in the chemical industry because of their reliability, quality and service life.
Due to the unique design, the safety clamp gives an evenly distributed pressure all around, without damaging the hose. In addition to the proven quality over many years, the Bundesanstalt für Materialprüfung in Berlin (BAM) has also tested that the clamp can be used up to at least 300 kg/cm2 (300 bar / 4,400psi) gas and liquid pressure, when the clamp is used with hose connections with a hose pillar.
This version has a Bolt SW 7 (S), length of the bolt (M6) is normal = 20 mm (N) and is available in 3 types of material:
- Standard: 1.0330 (galvanized after machining), 2.0321, 2.0401, 2.0371, 1.4310.
- Stainless Steel: 1.4310, 1.4567, 1.430
- Conductive: 2.0321, 2.0401, 2.0371, 2.1020 (and anti-magnetic)
How to order:
- First choose your material type in the menu at the top right
- Then choose the diameter you need
- Then choose the number of clamps you need. (Minimum of 100 pieces)
- Send an email to [email protected] with details from your order.
- You have now requested a quote for your order!
In addition to this version, we have many other versions available for you in our webshop:
- Slot 1.20 mm, with bolt length Short (K) and Long (L)
- Hand cap SW 25, (H series), with bolt length Normal (N) and long (L)
- Bolt SW 7 (S series), with bolt length long (L)
- Wing nut (F-series) ), with bolt length Normal (N) and long (L)
(Short (K) = 13 mm, Normal (N) = 20 mm and Long (L) = 25 mm)
And all in the variants Standard, Stainless Steel and Conductive !!!
In short: Here you are guaranteed to find a suitable high-quality safety clamp.
Specifications
| Bolt: | M6 |
| Bandwidth: | 4,5 mm |
| Tightening torque (Maximum): | 1,5 Nm |
