Silicone OAT cooling water hose in lengths of 1, 2, 3 and 4 meters
| Article number: | IQP-WHL-016-GR |
| SKU: | IQP-WHL-016-GR |
- 2 year warranty
- Delivery time: 2 - 3 weeks
Silicone Flexible Hoses consist of an integral liner, 3 plys of polyester reinforced, a 1.2mm thick galvanised steel wire helix running inside the wall of the hose and a convoluted outer.
The result is a supremely flexible hose suitable for coolant and air applications with benefits such as optimum performance across a temperature range of -70°C to +170°C.
Silicone Flexible Hoses is capable of withstanding high, positive pressures with virtually no dilation and strong negative pressures, with excellent resistance to deformation or, collapse. The Silicone Flexible hose is resistant to UV and ozone and exceeds the requirements of SAE J20 Class A. Silicone Flexible Hose is suitable for use with all ethylene glycol coolants.
They can be easily fitted onto applications which may otherwise have required a shaped hose to be supplied. In this situation the Silicone Flexible hose provides a quick fix solution and eliminates tooling costs.
| Bore mm | Bore Inch | No. of Ply | Rubber Thickness | Wire Thickness | Max Length mtrs |
| 12.7 | 1/2 | 3 | 4mm | 1.2mm | 4 |
| 16 | 5/8 | 3 | 4mm | 1.2mm | 4 |
| 19 | 3/4 | 3 | 4mm | 1.2mm | 4 |
| 22 | 7/8 | 3 | 4mm | 1.2mm | 4 |
| 25.4 | 1 | 3 | 4mm | 1.2mm | 4 |
| 28 | 1 1/18 | 3 | 4mm | 1.2mm | 4 |
| 30 | 3 | 4mm | 1.2mm | 4 | |
| 32 | 1 1/4 | 3 | 4mm | 1.2mm | 4 |
| 35 | 1 3/8 | 3 | 4mm | 1.2mm | 4 |
| 38 | 1 1/2 | 3 | 4mm | 1.2mm | 4 |
| 41 | 1 5/8 | 3 | 4mm | 1.2mm | 4 |
| 45 | 1 3/4 | 3 | 4mm | 1.2mm | 4 |
| 48 | 1 7/8 | 3 | 4mm | 1.2mm | 4 |
| 51 | 2 | 3 | 5mm | 1.2mm | 4 |
| 55 | 2-1/8 | 3 | 5mm | 1.2mm | 4 |
| 57 | 2 1/4 | 3 | 5mm | 1.2mm | 4 |
| 60 | 2 /8 | 3 | 5mm | 1.2mm | 4 |
