HCL Smart® Band Standard 10 mm PA66 | Buckle

HCL Smart® Band Standard 10 mm / PA66 | Band & Buckle

Smart® Band Standard is a non-metallic band and buckle system. It is a highly intuitive product making it very easy to fit. It is the ideal strapping solution for less aggressive applications both on and offshore. It is often used in permanent and temporary sign & street furniture fixation.

Smart® Band Standard system is available in a variety of materials, sizes and reel lengths. It offers long-life and non-corrosive properties, making it the ideal alternative to many high grade stainless steel strapping solutions.

• Type: Standard
• Band Compatibility: 10mm PA66
• Max System Strength kgf / lbf: 177 / 390
• Minimum Diameter mm / inch: 75.0 / 3.0
• Maximum Diameter mm / inch: 600.0 / 23.6
• Max Temp Resistance °C / °F: 125 / 257
• Flammability Rating: V-2
• Buckle Height mm / in: 21.5 / 0.85
• Buckle Length mm / inch: 77.2 / 3.0
• Buckle Width mm / inch: 22.9 / 0.90
• Material: PA66
• Tool Compatibility: SM-FT-2000-13

NOTE: The HCL Smart® Band 10 mm and the Buckle must be ordered separately!

Click HERE to order the 30 meter Band.

HCL numbers;

SB-BA-3/8-30M-PA66 - SB-BU-3/8-ST-PA66
