TEFEN Plastic Quick Release Socket BSPT Female
Brand:
TEFEN
- Buy 25 for €11,79 each and save 10%
- Buy 50 for €10,48 each and save 20%
| Article number: | TEF-8380-13-00 |
| SKU: | 22080004000 |
- 2 year warranty
- Delivery time: 1 week after order date
- Customer service 09:00 - 17:00
Information
TEFEN Plastic Quick Release Socket BSPT Female
The special quick connector offers a fast and reliable push-to-connect mechanism.
The movable outer sleeve locks the plug into the socket.
When the plug is disconnected, the socket acts as a shut-off valve.
A variety of plugs can be connected and used, according to hydraulic or pneumatic needs.
The movable outer sleeve locks the plug into the socket.
When the plug is disconnected, the socket acts as a shut-off valve.
A variety of plugs can be connected and used, according to hydraulic or pneumatic needs.
Material:
Internal parts: Acetal copolymer
Body: Nylon
Spring: stainless steel 316
O-ring: NBR
Applications: Food industry, dental air and water, drinking water, laboratories, compressed air systems, environmental technology, medical technology.
Working pressure: up to 14 bar at 20 ºC.
Temperature range: 4 ° C - 90 ° C
Flow: 480 l / min
Product code:
22080004000 - 22081104002 - 83801300
